Features:
1. The shell is made of aluminum alloy by die casting, the transparent part is made of high strength toughened glass, and the outer layer is protected by iron mesh.
2. The outlet is made of metal compressed spoon with silicone gasket and extends 60cm high temperature resistant RVV cable outward.
3. Class IIC pure explosion-proof structure, containing sillicone sealing ring, with strong protection, moisture-proof, explosion-proof and other characteristics
4. The shell is made of high strength aluminum alloy, electrostatic spray molding.corrosion protection, water proof and explosion protection, which perfectly protect the core electrical components.
| parameter name | Numerical value | ||||||
| Rated voltage | 12V | 24V | 36V | 127V | 220V | 380V | |
| Voice division | ≥90dB(A) | ||||||
| power | 5~10W | ||||||
| LED Lamp | Operating mode | rotating | Blasting flash | Normally on | Stroboscopic | ||
| Light color | Red | Yellow | Blue | Green | White | ||
| Color rendering index | Ra≥80 | ||||||
| Beam angle | 360° | ||||||
| Service life | 50000H | ||||||
| Drive power | Current | 0.05A | |||||
| Power Factor | PF≥0.97 | ||||||
| Power Efficiency | ≥90% | ||||||
| Frequency Range | 50-60Hz | ||||||
| Operating temperature | -40~+50℃ | ||||||
| Explosion-proof mark | Exd IIC T6 Gb/DIP A20 TA,T6 | ||||||
| Enclosure rating | IP66 | ||||||
| Anti-corrosion grade | WF2 | ||||||
| Inlet dart pattern specifications | G3/4" | ||||||
| Applicable cable outer diameter | Ф8-14mm | ||||||
| Dimensions | Ф160x210mm | ||||||
| product weight | 1.80Kg | ||||||
